Plc Touch Screen Milk Pasteurization Equipment With Plate Heat Exchanger

Name: Plc Touch Screen Milk Pasteurization Equipment With Plate Heat Exchanger
Brand: Beyond
Price: 1 USD

Quality Plc Touch Screen Milk Pasteurization Equipment With Plate Heat Exchanger for sale

Brand Name : Beyond

Model Number : 500L-200000L

Certification : CE certificate/ISO9001/SGS

Place of Origin : China

MOQ : 1

Price : negotiable

Supply Ability : 20 pcs per month

Delivery Time : 60-90 days

Packaging Details : wooden box

Name : pasteurizer

material : SUS304 or SUS316

function : used for milk or juice

sterilizing technology : 5℃ -（85-95℃-15s）- 5℃

type : plate type

operation : full-auto or semi-auto

Contact Now

Pasteurizer milk Pasteurization Equipment juice pasteurizer SUS304 500L

Plate pasteurizer(3 sections):
Application: This unit is used as Pasteurizer (widely used in fresh milk, milk beverage, juice, tea, alcohol, ice cream etc.), and also pre-sterilize material when producing sterilized milk (long life milk).

Features:
This unit can be connected with separator, homogenizer, flash evaporator & degasser etc.

This machine has features of high heat recovery efficiency, low energy cost, compact design on the construction and easy operation, simple maintenance.

Save time and reduce the risk of human error
This function can produce a certain amount of milk and cream, which can be set to a certain number of liters, or it can be programmed to continue production until the storage tank is full (or the source tank is empty). If connected to separators and standardization devices, specific fat content can also be defined. It can switch to CIP and automatic operation without manual intervention.

Process design and parameter

Production capacity:	500L-20000/H
Technical Parameter:	5℃→65℃(homogenization)→85℃(15S) →5℃
Control type:	Full-automatic control (PLC with touch screen), semi automatic.
Equipment configuration	A. plate heat exchanger; B. material-balance bucket; C. Hot water-balance drum; D. hot water pump; E. product pump; F. steam & water mixer; G. electricity box; H. stainless steel pipes and valves etc. I.PLC and color touch screen;

Technical Parameter:

Model	Capacity	Heat exchane area (m²)	Total power (kw)	Steam consumption (kg/h)	Dimension (L×W×H)mm	Machine weight (kg)
BR16-BS-0.5	0.5	5	5.2	52	1200×1200×1500	790
BR16-BS-1	1	8	5.2	60	1500×1500×1800	880
BR16-BS-2	2 t/h	13	6	104	1800×2000×1800	980
BR26-BS-3	3 t/h	20	6	156	2000×2000×2200	1080
BR26-BS-4-5	4-5 t/h	30-45	8	260	2250×2000×2200	1250
BR26-BS-6-8	6-8 t/h	35-50	8	400	2250×2000×2200	1250
BR26-BS-10	10 t/h	60	11	520	2800×2000×2200	1650
BR35-BS-15	15 t/h	75	11	780	3000×2200×2200	2150
BR35-BS-20	20 t/h	80	11	945	3300×2200×2200	2350

Plc Touch Screen Milk Pasteurization Equipment With Plate Heat Exchanger

Technical Parameter:

Model	Capacity	Heat exchane area (m²)	Total power (kw)	Steam consumption (kg/h)	Dimension (L×W×H)mm	Machine weight (kg)
BR16-BS-0.5	0.5	5	5.2	52	1200×1200×1500	790
BR16-BS-1	1	8	5.2	60	1500×1500×1800	880
BR16-BS-2	2 t/h	13	6	104	1800×2000×1800	980
BR26-BS-3	3 t/h	20	6	156	2000×2000×2200	1080
BR26-BS-4-5	4-5 t/h	30-45	8	260	2250×2000×2200	1250
BR26-BS-6-8	6-8 t/h	35-50	8	400	2250×2000×2200	1250
BR26-BS-10	10 t/h	60	11	520	2800×2000×2200	1650
BR35-BS-15	15 t/h	75	11	780	3000×2200×2200	2150
BR35-BS-20	20 t/h	80	11	945	3300×2200×2200	2350
